Application of detachable plate heat exchanger as steam generator
Click number:- Release time:2020-06-16

Detachable plate heat exchanger as a steam generator usually uses industrial steam as the heating source, then pure water is heated to produce clean steam. It is used in processes that require clean and dry steam for direct processing, such as food, beverages, electronics, pharmaceuticals and nuclear power. It is mainly used in processes that require clean, dry steam for direct processing, such as food, beverages, electronics, medicine and nuclear power. Industries and humidifying occasions with clean steam requirements.



Overall construction.

The clean steam generator is mounted on a stainless steel frame and is supplied as a complete machine. The main structure consists of an industrial steam control section, a clean steam control section and a plate heat exchanger section.



Application process.

Pure water is pressurized by electric pump, then preheated by preheating plate heat exchanger, and then enters the steam heat exchanger, and after heating, passes through the The soda-water mixture enters the separation tank. The separation of steam and water is achieved, the dry steam is exported from the upper outlet to the steam equipment, and the water level in the separation tank is controlled by an automatic water level controller. Set the water level. At the same time, the automatic blowdown control system continuously detects the conductivity of the water in the separation tank. When the conductivity exceeds the standard, the automatic blow-off valve is opened automatically, thus ensuring the quality of water and steam.

 plate heat exchanger as steam generator

The industrial steam is condensed after heat exchange in the steam-water heat exchanger, and the resulting condensate enters the preheated heat exchanger to heat additional pure water. This results in the full utilization of energy. Accelerate the rate of clean steam generation, reduce the volume and cost of the main heat exchanger.



Well, Detachable plate heat exchanger as a steam generator on the above-mentioned applications, if there are other aspects of the application, you can contact us, Qingdao Ruipute Heat Exchanger Equipment Manufacturing Co.
